The Portable Hydraulic Trainer consists of actual industrial grade hydraulic components and parts which are commonly apply and used in industrial field. It is classified into basic level training experiments. It is easily customizable in modular format for the logical analysis of electric circuits, design and wiring in hydraulic and electro-hydraulic training experiments, which is included electric control for hydraulic sequence control. The expansion and compatibility of this modular system was taken into consideration. It uses a standard grip-on profile panel for common use of all the training set. Each part could be horizontally or vertically attached and detached on the profile panel without any tools.

Curriculum Coverage

• Valve 4/3 works with electrical service.
• The cylinder works two ways.
• Set of control devices
• Oil pressure display etc.
