Is a set of experiments designed and built for theoretical training covering the properties of the Power electronics devices, such as DIODE, SCR, TRIAC, BJT, MOSFET, IGBT, etc., and can be used to operate various power electronics such as AC to DC, AC to DC, DC to AC, three phase control rectifier , Three phase inverter, etc.

Curriculum Coverage

• V-I characteristic of power diode in AC circuit
• V-I Characteristic of SCR in AC circuit
• Single-Phase half wave controlled rectification circuit
• Three-Phase fully controlled bridge rectification circuit
• V-I Characteristic of TRIAC in AC circuit
• Single-Phase Uni-Directional controlled circuit ,etc.
